Product
Bioreactor & fermenter for research
and development
BIOCNS Lab Series
The Lab Series BIOCNS L is a laboratory-scale bioreactor system optimized for a wide range of microbial and cell culture applications,
available in LS(Stand Type) and LB(Bench Type) configurations.
Both models are based on the same control system and cultivation performance; microorganism cultivation is supported as standard,
and animal cell/genetic cell cultivation can be configured through optional selections.
Features
- Stand- and bench-type configurations optimized for laboratory use
- Flexible agitation options with multiple impellers
- Stable and uniform agitation with detachable SUS316L triple baffles
- High-precision PID control of temperature, pH, and DO
- Accurate gas control via individual gas lines (MFC or flowmeter)
- Optional ring or mesh spargers with 0.2 µm filtration
- User-customizable HMI with real-time trends and data logging
- Optional auto sampling for enhanced operational efficiency
- Optional features for animal cell culture, including low-shear agitation
BIOCNS L Series Product Code Classification
BIOCNS L Series
BIOCNS-LB-05S
BIOCNS-LB-05D
BIOCNS-LS-05S
BIOCNS-LS-05D
(Shown with optional Auto Sampler (Model: BIOCNS-A))
Technical Advantages
The BIOCNS LS/LB Series is designed with an efficiency-optimized structure and precise control system to support a wide range of microbial and cell culture processes.
Advanced agitation and gas control technologies enable high-density cultivation, while indirect heat exchange vessel design ensures stable and reproducible temperature control.
The same vessel geometry and structure as Pilot/Plant systems enable scale-up from R&D to production.
Control System
- Intuitive control of all cultivation conditions on a single screen
- At-a-glance view of setting and process values (SV / PV)
- Real-time data logging with trend visualization
- One-touch start and stop for efficient operation
Model Structure
toggle| Category | Stand Type | Bench Type |
|---|---|---|
| Model | BIOCNS LS | BIOCNS LB |
| Volume | 1 / 3 / 5 / 7 / 10 L | |
| Configuration | Single / Double | |
| Type | Standing | Benchtop |
General
toggle| Category | Item | Specification / Description |
|---|---|---|
| Vessel Specification | Vessel Volume / Working Volume | 1 L / 3 L / 5 L / 7 L / 10 L (Standard; customizable per vessel) |
| Agitation Speed | 50–1,200 RPM (Microbial) / 0–1,000 RPM (Cell culture option) | |
| Impeller Type | Rushton / Marine / Elephant Ear (selectable) | |
| Operating Temperature | 4–80 °C (Accuracy ±0.1 °C) / 4℃-50℃ (±0.1 ℃) (Cell culture option) | |
| Vessel Material | Borosilicate glass, Stainless steel 316L | |
| Adjustable Ports | pH, ORP (REDOX), DO, Thermo well, Baffle, Foam, Inoculation, Sampling, Feeding | |
| Exhaust Condenser | Stainless-steel condenser mounted on the head plate | |
| Sensors | Sensor Types | pH / DO / OD / ORP / Foam / Level / Temperature |
| Balance Control | RS-232C communication; weight measurement via integrated scale | |
| Level Sensor Control | Electrode-type high/low level control | |
| Pressure Control | Automatic pressure control (up to 1.5 bar) | |
| Gas Analyzer (Option) | CH₄, O₂, CO₂, NH₃, N₂ monitoring | |
| Pumps | Peristaltic Pumps | 3 built-in assignable pumps (standard 25 RPM duty cycle) |
| Control & Setting | PV/SV Control | pH, DO, Temperature, RPM, Air, Feeding |
| PID / On-Off Control | Precision PID control; on/off mode available | |
| Aeration | Sparger | Ring or Mesh sparger with 0.2 µm disposable filter |
| Software | HMI Software | Real-time data logging, alarms, and trend graph display |
| Controller | Control Unit | Embedded PC or PC + integrated control board |
| GMP | Validation | IQ / OQ (21 CFR Part 11 compliant) |
Electrical & Utilities
toggle| Item | Specification / Description |
|---|---|
| Power Supply | 100–240 V, 50/60 Hz, Single phase |
| Fuse Capacity | 10A |
| Ambient Conditions | 0–50 °C, ≤85% RH |
| Weight | 30–60 kg (depending on model and vessel volume) |
